XFP LR

OCRECOM’s XFP transceiver is a high performance, cost effective modules for series optical data communications applications specified for signal rates of 9.95 Gb/s to 11.3 Gb/s. It is fully compliant to XFP MSA Rev 4.5. The modules are designed for single mode fiber and operates at a nominal wavelength of 1310nm, XFP LR. The transmitter section incorporates uncooled directly modulated 1310nm DFB Laser. The receiver section uses PIN photo detector for low dark current and excellent responsivity.
  • Features
  • Application
  • Model Ordering Information

    u  Supports 8.0Gb/s to 11.1Gb/s bit rates

    u  Hot-pluggable XFP footprint, Built-in digital diagnos

    u  Maximum link length of 10KM with SMF

    u  1310nm DFB laser and PIN photodiode

    u  XFP MSA package with duplex LC connector

    u  No reference clock required

    u  Single +3.3V power supply

    u  Power dissipation <1.5W

    u  Compatible with RoHS

    u  Temperature range0 to +70°C

    u  SONET OC-192&SDH STM-64 at 9.953Gbps

    u  10GBASE-SR/SW 10G Ethernet

    u  1200-MX-SN-I 10Gigabit Fiber Channel

    u  10GE over G.709 at 11.09Gbps

    u  OC192 over FEC at 10.709Gbps

    u  Other optical links, up to 11.3Gbps

    PN

    Description

    OF6S341

    XFP  LR 10Km  0~70

    OF6S342

    XFP  LR 10Km  -40~85
