XFP Bi-Di 40KM

OCRECOM’s BIDI XFP transceivers are designed for bi-directional 10G serial optical data communications such as IEEE 802.3ae 10GBASE-BX by using 1330(1270nm) transmitter and 1270(1330) nm receiver. The transceiver consists of two sections: The transmitter section uses a multiple quantum well 1330(1270) nm DFB laser and is a class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated 1270(1330) nm detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.
  • Features
  • Application
  • Model Ordering Information

    u  Supports 8.0Gb/s to 11.1Gb/s bit rates

    u  Hot-pluggable XFP footprint, Built-in digital diagnos

    u  Maximum link length of 40km with SMF

    u  1270/1330nm DFB laser and PIN photodiode

    u  XFP MSA package with duplex LC connector

    u  No reference clock required

    u  Single +3.3V power supply

    u  Power dissipation <1.5W

    u  Compatible with RoHS

    u  Temperature range0 to +70°C

    u  SONET OC-192&SDH STM-64 at 9.953Gbps

    u  10GBASE-LR/LW 10G Ethernet

    u  1200-SM-LL-L 10G Fibre Channel

    u  10GE over G.709 at 11.09Gbps

    u  OC192 over FEC at 10.709Gbps

    u  Other optical links, up to 11.1Gbps

    PN

    Description

    OFB6C03414

    XFP Bi-Di Tx1270nm/Rx1310nm  40KM LC DDMI 0~70C

    OFB6C30414

    XFP Bi-Di Tx1330nm/Rx1270nm  40KM LC DDMI 0~70C

    OFB6C03424

    XFP Bi-Di Tx1270nm/Rx1310nm  40KM LC DDMI -40~85C

    OFB6C30424

    XFP Bi-Di Tx1330nm/Rx1270nm  40KM LC DDMI -40~85C
