10G SFP+ ZR

OCRECOM's SFP+ transceiver are multi-purpose optical modules for 10Gb/s data transmission applications at 1550nm. The transceivers are ideally suited for datacom and storage area network (SAN/NAS) applications based on the IEEE 802.3ae and Fiber Channel standards, Fiber Channel 10G, 8.5G, 4.25G, 2.125G, 1.0625G, 10G BASE-ZR, 1000 Base-ZX Ethernet, SDH/SONET and Multi-rate SFP+ transceivers.
  • Features
  • Application
  • Model Ordering Information

    u  Hot pluggable

    u  10Gb/s serial optical interface

    u  1550nm cooled EML transmitter with TEC, High sensitivity APD Receiver

    u  Up to 80km on 9/125um SMF

    u  SFP+ MSA package with duplex LC connector

    u  2-wire interface for management and diagnostic monitor

    u  SFI High Speed Electrical Interface

    u  Very low EMI and excellent ESD protection

    u  +3.3V single power supply

    u  Power consumption less than 1.5W

    u  Operating case temperature: 0~+70°C

    u  Compliant with SFF-8431 and SFF-8432

    u  Compliant with SFF-8472 Rev 10.2

    u  Compliant with IEEE 802.3ae 10GBASE-ZR and 10GBASE-ZW

    u  RoHS Compliant

    u  10G Base-ZR/ZW

    u  Fiber Channel (with/without FEC)

    u  10G Storage system

    u  Other optical links

    PN

    Description

    OE6S5418

    10G SFP+ ZR 80KM 0~70
