XFP Bi-Di 10KM

OCRECOM’s BIDI XFP transceivers are designed for bi-directional 10G serial optical data communications such as IEEE 802.3ae 10GBASE-BX by using 1330(1270nm) transmitter and 1270(1330) nm receiver. The transceiver consists of two sections: The transmitter section uses a multiple quantum well 1330(1270) nm DFB laser and is a class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated 1270(1330) nm detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.

see details

XFP ZR

OCRECOM's XFP transceiver is a high performance, cost effective module for serial optical data communications applications specified for signal rates of 9.95 Gb/s to 11.3 Gb/s. It is fully compliant to XFP MSA Rev 4.5. The modules are designed for single mode fiber and operates at a nominal wavelength of 1550 nm, XFP ZR. The transmitter section incorporates EML cooled laser 1550nm. The receiver section uses APD high sensetivity receiver.

see details

XFP ER

OCRECOM’s XFP transceiver is a high performance, cost effective modules for series optical data communications applications specified for signal rates of 9.95 Gb/s to 11.3 Gb/s. It is fully compliant to XFP MSA Rev 4.5. The modules are designed for single mode fiber and operates at a nominal wavelength of 1550nm, XFP ER. The transmitter section incorporates uncooled directly modulated 1550nm EML DFB Laser. The receiver section uses PIN photo detector for low dark current and excellent responsivity.

see details

XFP LR

OCRECOM’s XFP transceiver is a high performance, cost effective modules for series optical data communications applications specified for signal rates of 9.95 Gb/s to 11.3 Gb/s. It is fully compliant to XFP MSA Rev 4.5. The modules are designed for single mode fiber and operates at a nominal wavelength of 1310nm, XFP LR. The transmitter section incorporates uncooled directly modulated 1310nm DFB Laser. The receiver section uses PIN photo detector for low dark current and excellent responsivity.

see details

XFP SR

OCRECOM’s XFP transceiver is a high performance, cost effective modules for series optical data communications applications specified for signal rates of 9.95 Gb/s to 11.3 Gb/s. It is fully compliant to XFP MSA Rev 4.5. The modules are designed for single mode fiber and operates at a nominal wavelength of 850nm, XFP SR. The transmitter section incorporates uncooled directly modulated 850nm VCSEL Laser. The receiver section uses PIN photo detector for low dark current and excellent responsivity.

see details
