SFP Dual fiber MM

The IEEE 802.3z standard includes 1000BASE-SX/100BASE-SX for transmission over multi-mode fiber, it uses a 1310nm FP or 850nm VCSEL transmit to 300m/550m/2KM. OCRECOM’s SFP MM transceiver including 155M, 1.25G, 2.5G, 4.25G.
  • Features
  • Application
  • Model Ordering Information

    u  High Quality 850nm VCSEL/ 1310nm FP

    u  Compliant with ITU-T G.957,G.958

    u  Multi-Source Package with Duplex LC Connector

    u  Up to 4.25Gb/s

    u  850nm VCSEL/1310nm FP Multi-Mode

    u  Single +3.3V Power Supply

    u  Hot-Pluggable

    u  Eye Safety Designed to Meet Laser Class1, Compliant with IEC60825-1

    u  RoHS Compliant Products

    u  SONET OC-3/SDH STM-1

    u  Fast/Gigabit Ethernet

    u  4.25Gbps Fibre Channel operation for FC-PI 400-M5-SN-I and 400-M6-SN-I

    u  2.125Gbps Fibre Channel operation for FC-PI 200-M5-SN-I and 200-M6-SN-I
    -

    u  1.0625Gbps Fibre Channel operation for FC-PI 100-M5-SN-I and 100-M6-SN-I

    u  Fiber Channel

    u  Switch to Switch Interface

    u  Switched Backplane Applications

    u  Router/Server Interface

    u  Other Optical Links

    PN

    Description

    OB1M8213

    SFP   transceiver, 155M  MM 850nm 2KM  LC 0~70 +3.3V

    OB1M8223

    SFP   transceiver, 155M  MM 850nm 2KM  LC -40~85 +3.3V

    OB1M8413

    SFP   transceiver, 155M  MM 850nm 2KM  LC DDMI 0~70 +3.3V

    OB1M8423

    SFP   transceiver, 155M  MM 850nm 2KM  LC DDMI -40~85   +3.3V

    OB1M3213

    SFP   transceiver, 155M  MM 1310nm 2KM  LC 0~70 +3.3V

    OB1M3223

    SFP   transceiver, 155M  MM 1310nm 2KM  LC -40~85 +3.3V

    OB1M3413

    SFP   transceiver, 155M  MM 1310nm 2KM  LC DDMI 0~70 +3.3V

    OB1M3423

    SFP   transceiver, 155M  MM 1310nm 2KM  LC DDMI -40~85   +3.3V

    OB2M821

    SFP   transceiver, 1.25G  MM 850nm 550M  LC 0~70 +3.3V

    OB2M841

    SFP   transceiver, 1.25G   MM 850nm 550M  LC DDMI 0~70 +3.3V

    OB2M822

    SFP   transceiver, 1.25G  MM 850nm 550M  LC -40~85 +3.3V

    OB2M842

    SFP   transceiver, 1.25G  MM 850nm 550M  LC DDMI -40~85   +3.3V

    OB3M821

    SFP   transceiver 2.5G MM 850nm 300M LC 0~70 +3.3V

    OB3M822

    SFP   transceiver 2.5G MM 850nm 300M LC -40~85 +3.3V

    OB3M841

    SFP   transceiver 2.5G MM 850nm 300M LC DDMI 0~70 +3.3V

    OB3M841

    SFP   transceiver 2.5G MM 850nm 300M LC DDMI -40~85 +3.3V

    OBEM841

    SFP   transceiver, 4.25G MM 850nm 300M LC DDMI 0~70 +3.3V

    OB   EM842

    SFP   transceiver, 4.25G MM 850nm 300M LC DDMI -40~85 +3.3V
